This menu is to properly and safely eject your USB device. Select USB Safely Remove and press OK button.
To complete the eject procedure select OK on the pop-up menu displayed. Select Cancel to stop the
ejecting.
7.4.7 WEATHER
Check the Weather in your area!
Use the COLOUR buttons to setup this simple app. Use pq or 0~9 buttons button to select a city
closest to you from the list and confirm with OK.
With the YELLOW button you can place the selected city at the top of the list, with the RED button you
can delete the selected city, with the GREEN button you can change from 5 to 10 days of forecast (and
vice versa).
In the case you want to add a new city, press the BLUE button and enter the name on the keyboard and
confirm with the GREEN key.
7.4.8 NEWS
In this menu it is possible to find news belonging to different categories such as Economy, Sport
technology etc. Use pq button to select the various categories and t u to select a news item. Pressing
OK displays the complete text.
With COLOR buttons it is also possible to edit the RSS list by adding or deleting the categories.
7.5 SMARTCARD TIVÙSAT
This menw allows you to find all information regarding your Conditional Access Subscription status but
can only be accessed when the channel is playing normally and the smart card is normally recognized.
n Smart card information
n Technical information
Smart card information Technical information
8.0 MEDIA
This menu gives the description of all the functions contained in the Media function.
There are three main categories within this menu highlighted in red at the top of the screen: Picture,
Music and Movie. To select them use the t u button. The content of the connected USB device is
displayed in the center. Use pq button to select the file, OK button to confirm and MENU button to
back to previous step.
NOTE: Once you have selected one of the 3 options (Picture, Music or Movie) the
receiver will display only the files belonging to that category. Example, if
Movie is selected, the receiver will not display audio files even if they are
present in the selected folder
19

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Strong SRT7807 and is the answer not in the manual?

Strong SRT7807 Specifications

Demodulator IconDemodulator
demodulationQPSK, 8PSK
input symbol rate1 ~ 45 Ms/s
FEC decoder DVB-S2 QPSK mode1/2, 2/3, 3/4, 5/6, 7/8
FEC decoder DVB-S2 8PSK mode1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
Video IconVideo
video standardMPEG-2, MP@ML, MP@HL, MPEG-4, AVC/H.264 MP@L4.2, HP@L4.2
max video resolution1080p
aspect ratio4:3 and 16:9
video resolution HDMI576i/576p, 720p, 1080i, 1080p
video resolution SCARTPAL
Audio IconAudio
audio standardMPEG-1, MPEG-2 layer I&II
Tuner IconTuner
tuner typeF Type, IEC169-24, Female 75ohm
input frequency range950 – 2150 MHz
signal level-60 to -25 dBm
LNB power13/18 V DC (+/- 1 V)
DiSEqC version1.0/1.1/1.2
System Memory IconSystem Memory
CPUM3528 2000DMIPS
flash memory28 MB NAND Flash
system memory256MB DDR3
Connectors IconConnectors
SAT INpresent
S/PDIF (coaxial)present
smartcard reader1x, on right side panel
HDMI 1.4bpresent
TV SCARTCVBS only
Ethernet (RJ45)present
IR (infrared)1x38KHz IR, NEC Protocol
power adapter12 V/1.5 A
USB 2.0 port Type A1x, 5 V/500 mA (max.) supported (with duster cover)
General Data IconGeneral Data
supply voltageAC 100 - 240 V 50/60 Hz
input voltageDC 12 V, 1.5 A
size (W x D x H)168 x 99 x 39 mm
net weight0.5 kg
