5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
EE4,2
wire AWG16
wires 2 x AWG18
Power Box
SMPS
24V / 3,2A
L
N
PE
POWER ENTRY MODULE
PLUG AC
F1 = F2 = 2,5AT (slow blow)
100-240V
50/60Hz
DRIVER FOR BRUSHLESS MOTOR
PE
BLD05
A3
D
14433110
wire AWG16
EE4,2
XPE2
STOP SWITCH
MOTOR
DRIVER
POTENTI OMETER
(FROM DRIVER)
TO
POTENTI OMETER
POWER 24VDC
KEYBOARD
12050427-1
Minitom PCB
belt cable
FORNT PANEL
STOP SWITCH
2 x S6,3 + cover
4
2
1
1
2
3
POTENTIOMETER
bottom view
POTENTI OMETER
(TO MINITOM PCB)
HALL-SENSOR
MOTOR PHASE
POWER SUPPLY
RD
BK
RD
WH
GN
BU
BK
BK
RD
YE
GY
WH
VT
BN = BROWN
BU = BLUE
GN = GREEN
YE = YELLOW
COLOR CODES (IEC757):
PK = PINK
BK = BLACK
VT = VIOLETT
OG = ORANGE
WH = WHITE
GY = GREY
RD = RED
GNYE = YELLOW-GREEN AWG16
BRUSHLESS MOTOR
L
N
PE
-V
+V
wire AWG16
EE4,2
XPE1
EE4,2
XPE4
Ma in
ChassisUpper plate
wire AWG16
EE4,2
XPE3
EE4,2
XPE5
wire AWG16
EE4,2
XPE6
EE4,2
XPE7
Front plate
Front plateBottom plate
Upper plate
S...Socket (S6,3 - faston socket 6,3mm...)
green...LABELS on the wires, cables, plates (BK1, W1, PE1...)
all AWG wires and cables have an UL/CSA approval
binding belt 100 x 2,5mm
KEY:
EE...Electric Eye (EE4,2 - Electric Eye with inside diameter 4,2mm...)
close to
rubber cover
close to
ground plate
GNYE-1
close to
bottom plate
on the
power box
(*1 )
on the
power box
(*2 )
close to
power box
between PCB
and power box
on the
power box
(*3 )
close to
PCB
BK2
BK1
BK2
BK1
RD3
RD4
RD4
RD3
RD1
RD2
RD2
RD1
BK
RD
RUBBER COVER
wires 2 x 0,75mm2
cable 3 x 0,25
3 x S6,3 + cover
(*1 )(*2 )
(*3 )
PLACIN G OF BELTS
PLACIN G OF BELT
W1
W2
W3
GY
WH
VT
WH
BN
GN
GN
BN
WH
W4
GROUND WIRE CONNECTIONS
shring tube
2 x SHRING TUBE 1/4 inch
3 x SHRING TUBE 1/8 inch
QS1
S1
A3
A1
A2
RP1
M1
STRUERS A/S
Pederstrupvej 84
DK-2750 Ballerup
Denma rk
wires 2 x 0,75mm2
GNYE-3
GNYE-4
GNYE-5
GNYE-1 GNYE-2
GNYE-2
REV B: OH (2007/02/26)
- A2 changed
- connection of RP1 changed
Rev C: JTV 25-04-2007:
PE1-7 -> XPE1- 7
Rev D: AKR 19-01-2012:
SMPS brand removed.
JUMPERS
Size
Scal e
CAGE Code
DWG NO
Rev
Sheet
of
Thursday, January 19, 2012
11
CIRCUIT DIAGRAM FOR MINITOM
<Cage Code>
Size
Scal e
CAGE Code
DWG NO
Rev
Sheet
of
Thursday, January 19, 2012
11
CIRCUIT DIAGRAM FOR MINITOM
<Cage Code>
Size
Scal e
CAGE Code
DWG NO
Rev
Sheet
of
Thursday, January 19, 2012
11
CIRCUIT DIAGRAM FOR MINITOM
<Cage Code>
2
43
1
X4
MINIFIT
2
43
1
X6
MICROFIT
START
1 2
1
2
X1
MINIFIT
231
X7
MICROFIT
1
2
3
4
X2
pin socket
21
X3
MSTBVA
STOP
1 2
F2
F1
