18 1025-009-001 REV E www.stryker.com
OPERATING THE PNEUMATIC FOWLER
Squeeze either or both of the yellow fowler handles (A) for pneumatic assist in lifting the fowler to the desired height as
shown in Figure 7. Remove hand(s) from handle when the desired height is achieved.
The optional drop seat fowler uses the weight of the patient for additional assistance with lifting the fowler. It also helps
keep the patient from sliding toward the foot end of the stretcher when the fowler is raised.
WARNING
Keep hands/fingers clear of the area around the fowler release handles and the fowler frame when lowering. Injury could
result if care is not taken when lowering the fowler.
Stretcher Operation
Return To Table of Contents
Figure 7 - Pneumatic Fowler
To Next Page
