5
Product Description and Intended Use
The 1688 4K Camera System with Advanced Imaging Modality (or “1688Video
Camera”) is an endoscopic camera system that is used to produce live video
in the surgical eld during surgical endoscopic procedures. The system is
sensitive in the visible and infrared spectrum. The optical image is transferred
from the surgical site to the camera head by a variety of rigid and exible
scopes, which are attached to the camera head. The system consists of a
camera console and a camera head with an integral cable that connects to the
console. A coupler is also available for attaching a scope to the camera head.
The available models for each part are listed below.
Console
1688010000 16884K Camera Control Unit with Advanced Imaging
Modality
Camera Heads
1688210080 16884K Microscope Camera Head, C-Mount
1, 2
1688210105 16884K Camera Head, C-Mount, with Advanced Imaging
Modality
1688310130 16884K Pendulum Camera Head with Integrated Coupler
3
1688610122 16884K Camera Head, Integrated Coupler, with Advanced
Imaging Modality
1688710105 16884K Inline Camera Head, C-Mount, with Advanced
Imaging Modality
Coupler
1688-020-122 4K Coupler, C-Mount, with Advanced Imaging Modality
4
1
Complete instructions are available in Stryker user manual P45082. Note that 1688210080 does not have the same intended use
or indications as stated in this user manual.
2
Not intended for use with SPY/ENV modes.
3
Not compatible with SPY/ENV modes.
4
Complete instructions are available in Stryker user manual P40880.
Note: For complete system requirements to use the camera’s SPY mode,
see the user manual for the L11 LED Light Source with Advanced Imaging
Modality (0220230300), also referred to as the “L11 LED Light Source.”
The camera console is also packaged with the following connection cables:
• Remote cables, 2.5 mm to 3.5 mm (Qty: 2)
• HDMI high speed cable (Qty: 1)
• Hospital-grade power cord (Qty: 1)
