Service
Low Air Loss (LAL) fan replacement (Continued)
Figure 1-28: LAL fan
15. Reverse steps to reinstall.
Notes
• During reinstall, make sure to align the Velcro® patches.
• After installation, remove the zipper pull tool or equivalent from the zipper.
• Make sure that the watershed covers the zipper.
16. Verify proper operation before returning the product to service.
