Stryker Performance-PRO XT - Side to Side Positioning of the Safety Hook; Installing the Safety Hook

FFiigguurree 66 –– SSaaffeettyy bbaarr sseeccuurreedd iinn tthhee vveehhiiccllee ssaaffeettyy hhooookk
A
B
C
DE
FFiigguurree 77 –– VVeehhiiccllee ssaaffeettyy hhooookk ppllaacceemmeenntt
A Top view of vehicle
B Vehicle safety hook
C Squad bench
D Bumper
E Door frame
After installation, make sure that the cot legs lock into the load position without contacting the vehicle bumper.
