OOppeerraattiioonn
SSeettttiinngg ccoott llooaadd hheeiigghhtt
CCAAUUTTIIOONN -- Always set the cot load height before you place the cot into service.
Adjust the cot load height to match the vehicle deck. If the cot does not line up correctly, you may also adjust the cot load
height.
To set the cot load height:
1. Roll the cot the loading area of your vehicle.
2. Compare the difference between the deck height of the vehicle and the load height of the cot.
3. Select high, mid, or low depending on the cot load height requirements.
FFiigguurree 88 –– SSeett ddeessiirreedd ccoott llooaadd hheeiigghhtt
CCoott llooaadd hheeiigghhtt FFoorr ddeecckk hheeiigghhttss
High Above 32 in.
Mid Between 30-32 in.
Low Below 30 in.
4. Make sure that the cot safety bar connects with the vehicle safety hook every time when you unload the cot in a variety
of positions. If the cot safety bar misses the vehicle safety hook, select the next lower height setting.
OOppeerraattiinngg gguuiiddeelliinneess
WWAARRNNIINNGG
• Do not allow untrained assistants to assist in the operation of the product.
• Always follow proper hand placement on hand grips. Keep all hands clear of the red safety bar pivots when you load or
unload the cot or change cot height position.
• Do not ride on the base of the cot.
• Do not transport the cot sideways to avoid the risk of tipping. Always transport the cot in a lowered position, head end or
foot end first to minimize the risk of tipping.
• Always keep hands, fingers, and feet away from moving parts. Use caution when placing your hands and feet near the
base tubes while you raise or lower the cot.
6086-209-001 Rev F.2 19 EN
