6390 Angle Position Sensor (APS) Calibration Instructions
2 www.stryker.com
8. Plugthemale-to-maleUSBcableintotheUSBportandtoanavailableUSBportonthelaptop.
Note: Make sure that the male-to-male USB cable will not get caught on anything while the Power-LOAD
system moves in and out of the vehicle patient compartment.
9. Double-clicktheStryker EMS USB Toolicononyourdesktop.Thetoolsoftwarewillautomaticallydetectthe
Power-LOAD.
10. AftertheStrykerEMSUSBtoolandPower-LOADareconnected,clickAdvanced andthenclickCalibrate APS.
11. IntheEnter Passwordfield,enterStryker1andclickEnter.
12. Loadthecotintothevehicle:
• For cot models 6500/6506 & 6510/6516:
• Pressandholdtheretract(–)buttononthecotcontrolswitchtofullyretractthecotundercarriageuntil
thecotissupported.
• For cot models 6085/6086:
• Presstheup()buttononthePower-LOADcontrolpaneltoraisetheliftingarmstothehighestposition.
Note: The cot legs do not retract.
• Operator1(FootEnd)−Graspthecotframeatthefootend.Squeezeandholdthecotmanualrelease.
• Operator2(Side)−Stabilizethecotbyplacingonehandontheouterrail.Graspthebaseframe.After
thefootendoperatorhassqueezedthecotmanualrelease,retracttheundercarriagewithonehandand
holditinplace.
• Operator 1 (Foot End) - Release the cot manual release to lock the undercarriage in the retracted
position.Ensurethatthecotmanualreleaseisreleased.Ifitisnotreleased,thecotbasewillextend
preventingthecotfromlockinginthefastener.
13. Pushthecotintothevehiclepatientcompartmentuntilthefootendcotwheelsareoverthefloorofthevehicle
patientcompartment,butnotinthefullinandlockedposition.
