Full Upright Position
Grasp the top of the siderail,
pull outward and swing up
until it locks into the full
upright position.
Intermediate Position
Grasp the siderail release and
rotate the siderail until it locks
in the intermediate position.
Full Down Position
Grasp the siderail release
handle and rotate the siderail
until it is completely lowered.
Siderail Positions
Precision siderails are BackSmart
™
designed with one-hand operation and intermediate support
positions for patient assistance during bed entry and exit.
“Precision Siderails — Where You Need Them, When You Need Them”

Stryker S3 Specifications

General

Weight Capacity	500 lbs (227 kg)
Maximum Patient Weight	500 lbs (227 kg)
Bed Frame Material	Steel
Type	Hospital Bed
Bed Width	35 inches (89 cm)
Caster Size	5 inches (12.7 cm)
Electrical Requirements	120 VAC, 60 Hz
Width	35 inches (89 cm)
Power Requirements	120 VAC, 60 Hz
Power Backup	Battery backup available
Accessories	IV pole
Siderails	Yes
