Stryker S3 Quick Start Guide

Steer Pedal
Operation
The Steer Pedal is located on
the base of the bed behind the
head board.
To Activate
Push in on one side or
the other of the triangular
Steer Pedal to engage
(ON) or disengage (OFF).
For Your Safety
When the ON side is pressed,
the front right caster cannot
swivel. It is locked parallel to
the long axis of the bed, to
keep the bed straight and
provide a pivot point.
1
1

Stryker S3 Specifications

General

Weight Capacity	500 lbs (227 kg)
Maximum Patient Weight	500 lbs (227 kg)
Bed Frame Material	Steel
Type	Hospital Bed
Bed Width	35 inches (89 cm)
Caster Size	5 inches (12.7 cm)
Electrical Requirements	120 VAC, 60 Hz
Width	35 inches (89 cm)
Power Requirements	120 VAC, 60 Hz
Power Backup	Battery backup available
Accessories	IV pole
Siderails	Yes
