13
Connecting Power from the AC Adapter
The transmitter must be powered by the AC adapter provided in its
packaging. The receiver may be powered by the AC adapter provided in its
packaging or by using the provided Y-cable to draw power from the 32” 4K
surgical display. To power the receiver from the display, see the next section.
Follow these instructions to connect power to the transmitter and receiver
from the AC power adapter.
1. Using the provided power cord, connect the AC power adapter to a
hospital-grade outlet.
2. Insert the AC power adapter’s outlet plug into the transmitter’s or
receiver’s AC power inlet.
Connecting Power to the Receiver from a Display
Follow these instructions to connect power to a receiver that is mounted on
the back of a 32” 4K Surgical Display.
Periodically check the display’s power supply for usability.
Replace the power supply if needed.
1. Disconnect the display’s power supply from the 24 V input on the display.
2. Using the provided Y cable, connect the display’s power supply to the 24
V input on the display.
3. Insert the Y cable outlet plug into the receiver’s AC power inlet.
Setting up the SYNK®4K Wireless System
The SYNK®4K Wireless System can be set up in a number of di erent ways,
depending upon which video sources and other visualization equipment are
available. This section describes two generic con gurations.
Note: When the Connected OR Hub and two camera control units are used,
you can switch between Channels 1 and 2. Review the Connected OR Hub
Instructions for Use (P35947) for more information.
Please contact a Stryker representative for assistance.
Before connecting any device to the SYNK®4K Wireless System,
all devices must be installed according to their respective
instructions, and the combination of devices must meet the
electrical safety requirements of IEC 60601-1.
