17
Operation
Pairing is the act of creating a wireless link between a transmitter and a
receiver. A token is used to create the link, by inserting it into the token slot of
the transmitter to write discrete pairing data and then inserting the token into
the token slot of the receiver to read the pairing data. A transmitter can pair
with up to two (2) receivers. The same token may be used to create each pair,
or a di erent token may be used for each pair.
Once paired, a transmitter can wirelessly transmit video data to a receiver,
which can send the video data from its HDMI OUT port to a display. The
transmitter can also wirelessly transmit data to a receiver, which can send the
data from its remotes ports to a digital capture device.
Pairing the Devices Using a Temporary Token (Blue)
REF: 0105208884
To pair a transmitter with a receiver:
1. Power on the transmitter and receiver. The token LED remains o as the
devices perform startup functions.
2. When the LED pulses white, insert the temporary token into the token
slot on the transmitter.
3. When the token LED is green, remove the token from the transmitter.
4. Within 2 minutes and 30 seconds, insert the token into the token slot on
the receiver.
5. Remove the token from the token slot on the receiver when the token
LED ashes green.
• An audible tone sounds from the transmitter.
• The video feed appears on the display.
6. By repeating steps 4 and 5, you can link one additional receiver.
Note: Link a second receiver directly after linking the rst receiver. Do not
reconnect the token to the transmitter.
7. Store the token in the transmitter token slot when not in use.
Pairing the Devices Using a Permanent Token (Red)
REF: 0240030977 (Sold separately)
A permanent link may be desirable in certain cases. Please contact your
Stryker representative in order to permanently link the receiver(s) with a
speci c transmitter, as deemed appropriate. Once the transmitter/receiver set
has been permanently linked, the set will automatically link when powered
