INPUT
High impedance mono or TRS
stereo input (internal jumper
configurable).
EXP
Connect a standard TRS
expression pedal for continuous
control over any selectable knob
parameter. To select the knob
controlled by the expression
pedal, hold the TREMOLO
BYPASS footswitch during power
up. The first knob turned is then
assigned to the expression pedal.
The maximum position the knob
is turned up to becomes the
expression pedal “toe down”
maximum value.
STEREO OUTPUTS
Use left output for mono
operation.
ADD EVEN MORE CONTROL & FLEXIBILITY
Connect the optional Strymon Miniswitch to quickly access a saved favorite setting
or set a tap tempo for the tremolo. See strymon.net/support/flint for more details.
POWER
Use an adapter with the
following rating: 9VDC
center negative. 250mA
minimum.
