Stuart Turner Mainboost MJ3 VM - Horizontal Step 1

- 18 –
Horizontal Step 1:
a) Remove the Mainsboost vessel from its packaging and check to ensure it is
not damaged.
b) Carefully place the vessel on the mounting cradles. For stability, ensure the
mounting cradles are as far apart as possible but within the weld seams
Fig. 18b.
WARNING: depending on cylinder size this may require two people
to complete safely.
Remove the skirt by splitting open the clip as shown in Fig. 18a.
Vertical vessel
Fig. 17a Monobloc 22/28mm ULK
10 - 30 mm
Removal of skirt
Fig. 18a
10 - 30 mm
Mounting cradle
placement Fig. 18b
Fig. 17b 35/42/54mm ULK
