Fig 6.
Control panel.
Indicator buttons:
a) Pump is ‘ON’
b) Leakage detected in pipeline: Check where possible for leaks or contact
appropriately qualified person.
c) Voltage protection: Input voltage has fallen out of specification for pump,
contact appropriately qualified person for correction.
d) Dry run detected: refer to section 8.11.
“OPERATING
PRESSURE” display
shows current
actual pressure the
pump is producing.
SET PRESSURE
display shows the
pressure the pump
is currently set at.
Pressure increase
button
Pressure decrease
button
Start/Stop button
Reset button
q
b
c
d
