6 TECHNICAL SPECIFICATION
Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.
6.11 Noise: The equivalent continuous A-weighted sound pressure level at a
distance of 1 metre from the pumpset does not exceed 70 dB(A).
Pump Model
Flood Kit
50 Hz
46638
General
Guarantee 1 year
Approvals CE
Features
Pump type Submersible
Pump control Float switch
Carry handle
ü
Manual mode
ü
Automatic float switch
ü
Noise 35 dB(A)
Materials
Pump body Polypropylene
Impeller Plastic
Pump mechanical seal Double Lip
Performance
Maximum head (closed valve)
0.85 bar
(8.5 metres)
Maximum flow with 15 m hose 83 l/min @ zero head (hose laid flat), 80 l/min @ 2.0 m head
Minimum immersion depth Fully submerged
Maximum immersion depth 7 metres
Suction to remaining depth – manual mode 3 – 6 mm
Suction to remaining depth – automatic mode 75 mm
Maximum suspended particle size 5 mm
Min / Max water temperature Min 4
o
C / Max 35
o
C
Connections
Pump connections – outlet G 1½ female
Flat hose Hose Connector G 1½ female x G 1 male x 25 or 32 mm bore hose
Flat hose 32 mm lay flat x 15 metres long
Motor
Type Induction (thermal trip / auto reset)
Duty rating Continuous S1
Electrical
Power supply / phase / frequency 230 V a.c. / 1 / 50 Hz
Power consumption 508 Watts
Current (full load) 2.2 Amps
Fuse rating 5 Amps
Power cable (pre-wired) 10 metres
Physical
Enclosure protection IPX8
Width 410 mm
Depth 300 mm
Height (excluding hoses) 340 mm
Weight (including fittings) 9.2 Kg
