Input gain Min Max Max to output
Mic 10dB 55dB 60dB
Line 0dB 45dB 50dB
Stereo 4/5-6/7 0dB 10dB 10dB
Stereo 8/9-10/11 0dB 10dB 10dB
E.Q LF Mid HF Cut/boost dB/Octave
Mic/Line 50Hz 250-6kHz 12kHz +/-15dB 6
Stereo 4/5-6/7 45Hz 1.5kHz 12kHz +/-10dB 6
Stereo 8/9-10/11 45Hz 1kHz 12kHz +10/-36dB (max) 12
Mic/Line High pass filter 80Hz 18dB/octave
Noise
Mic EIN -127.5dBu
Signal to noise ratio >85dB (unweighted) with typical control settings
Dynamic range >105dB
Input Impedance Maximum signal level
Mic 5k ohm +10dBu
Line 15k ohm +20dBu
Stereo 4/5-6/7 10k ohm +22dBu
Stereo 8/9-10/11 47k ohm +22dBu
Outputs Impedance Nominal signal level Maximum signal level
Left-Right (XLR) 150 ohms +10dBu (int. adj. +4dBu) +28dBu (bal) +22dBu (unbal)
Left-Right (RCA/phono) 600 ohms -10dBV +8dBV
Mono (RCA/phono) 600 ohms -10dBV +8dBV
Booth (jack) 30 ohms +4dBu +22dBu
Booth (RCA/phono) 600 ohms -10dBV +8dBV
Aux (jack) 30 ohms +4dBu +22dBu
Headphones (jack) 30 ohms Optimal load impedance 150-200 ohms
Output power 400mW/ch into 150 ohms
Output power 100mW/ch into 32 ohms
Frequency response
20Hz - 20kHz +/-0.3dB
10Hz - 50kHz +/-1dB
RIAA (phono) magnetic cartridge equalization accurate to +/-0.3dB
Distortion
THD @ 1kHz 0.0035% Stereo line input to Left-Right output @ nominal level
Video switcher (A or B input selected on front panel)
A/B inputs: standard composite video signal on RCA/phono connectors, 75ohms input impedance
Output: single RCA/phono connector
A.C. power Voltage range Fuse
230V 220V-240V T160mAL
115V 110V-120V T200mAL
50/60Hz, 22Watts max.
Dimensions Width Height Depth
(mm/inches) 482/19" 266/10.5" 114/4.5"
When racked the unit occupies 6 rack spaces.
Weight net gross
6kg/13.2lb 8kg/17.6lb
