ASD ... CW2 1280
ø bauseits mm 64
Außengewinde Zoll 2 1/2
ASD 1280 CW2
© STULZ GmbH – all rights reserved EN/06.2017/G18D
cyberair 3PrO cw2 Original instructiOns
Diameter of the chilled water lines
Legend:
1 - chilled water inlet 1
2 - chilled water outlet 1
3 - power supply
4 - condensate drain
5 - control lines
6 - humidifier in-/outlet
7 - chilled water inlet 2
8 - chilled water outlet 2
unit rear side
Bottom view
ASD ... CW2
ø by client mm
external thread inch
