Stulz SplitAir3 SAL40 - Page 12

SERIE - SERIES - SERIE - SERIE
ORDINE - ORDER - BESTELLUNG - COMMANDE
DATA - DATE - DATUM - DATE
TS MIN (Refrigerante - Refrigerant - Kaltemittel - Refrigerant)
TS MAX (Refrigerante - Refrigerant - Kaltemittel - Refrigerant)
Modulo di valutazione - Evaluation Module -
Bewertungsverfahren - Procédure d'évaluation
Contiene gas fluorati ad effetto serra disciplinati dal protocollo di Kyoto - Device
containing HFC fluids causing greenhouse effect regulated by kyoto protocol - Das Gerät
erhält wie vom Kyoto-Protokoll geregelte Fluorkohlenwasserstoffe Treibhausgasen -
Dispositif contenant fluides HFC à effet de serre disciplinés par le protocole de Kyoto
Ermeticamente sigillato - hermetically sealed
Hermetische Verschluss - Scellè Hermetiquement
MADE IN ITALY
A
01/08/2016
2,45 kg
50 °C
85 °C
-10 °C
29,5 bar
20 bar
Tensione nominale - Rated voltage - Nennspannung - Tension
nominale
Avviamento/marcia - Starting/run current -
Anlaufstrom/Nennstrom - Demarrage/marche
76/13,4 A
MODELLO - MODEL - TYP - MODELE
N°
OP:
Potenza Assorbita - Input power - Leistungsaufnahme -
Puissance absorbee
2,81 kW (L27L35RH40%)
Carica gas - Filling capacity - Fuellmenge - Charge de gaz
Refrigerante tipo - Refrigerant type - Kaeltemittel - Refrigerant type
TSS (Max temp. Di stoccaggio - Max Storage temp. -
Max Lagertemperatur - Temp. Max d'emmagasinage)
91 kg
Peso - Weight - Gewicht - Poids
R407C
PS HP (Max pressione ammissibile HP - Max allowable pressure HP -
Max zulaessiger Druck HP - Pression max admise HP)
PS LP (Max pressione ammissibile LP - Max allowable pressure LP -
Max zulaessiger Druck LP - Pression max admise LP)
CAT PED
I
SAO800RS00CZ00 7035
Grado di Protezione IP - Degree of protection IP - Schutzart IP -
Degré de protection IP
IP X4
CONDIZIONATORE D'ARIA - AIR CONDITIONER
KUHLAGGREGAT - CONDITIONNEUR
Kw
Potenza assorbita in riscaldamento - Heating power consuption -
Verbrauch in heizung - puissance absorbée en chauffage
230V 1 50Hz ~
SERIE - SERIES - SERIE - SERIE
ORDINE - ORDER - BESTELLUNG - COMMANDE
DATA - DATE - DATUM - DATE
TS MIN (Refrigerante - Refrigerant - Kaltemittel - Refrigerant)
TS MAX (Refrigerante - Refrigerant - Kaltemittel - Refrigerant)
Modulo di valutazione - Evaluation Module -
Bewertungsverfahren - Procédure d'évaluation
Contiene gas fluorati ad effetto serra disciplinati dal protocollo di Kyoto - Device
containing HFC fluids causing greenhouse effect regulated by kyoto protocol - Das Gerät
erhält wie vom Kyoto-Protokoll geregelte Fluorkohlenwasserstoffe Treibhausgasen -
Dispositif contenant fluides HFC à effet de serre disciplinés par le protocole de Kyoto
Ermeticamente sigillato - hermetically sealed
Hermetische Verschluss - Scellè Hermetiquement
MADE IN ITALY
A
01/08/2016
kg
60 °C
85 °C
-10 °C
- bar
- bar
Tensione nominale - Rated voltage - Nennspannung - Tension
nominale
Avviamento/marcia - Starting/run current -
Anlaufstrom/Nennstrom - Demarrage/marche
10,2/3,8 A
MODELLO - MODEL - TYP - MODELE
N°
OP:
Potenza Assorbita - Input power - Leistungsaufnahme -
Puissance absorbee
1,5 kW ()
Carica gas - Filling capacity - Fuellmenge - Charge de gaz
Refrigerante tipo - Refrigerant type - Kaeltemittel - Refrigerant type
TSS (Max temp. Di stoccaggio - Max Storage temp. -
Max Lagertemperatur - Temp. Max d'emmagasinage)
54 kg
Peso - Weight - Gewicht - Poids
PS HP (Max pressione ammissibile HP - Max allowable pressure HP -
Max zulaessiger Druck HP - Pression max admise HP)
PS LP (Max pressione ammissibile LP - Max allowable pressure LP -
Max zulaessiger Druck LP - Pression max admise LP)
CAT PED
I
SSI80HRS200Z00 7035
Grado di Protezione IP - Degree of protection IP - Schutzart IP -
Degré de protection IP
IP X0
CONDIZIONATORE D'ARIA - AIR CONDITIONER
KUHLAGGREGAT - CONDITIONNEUR
1,5 Kw
Potenza assorbita in riscaldamento - Heating power consuption -
Verbrauch in heizung - puissance absorbée en chauffage
230V 1 50/60Hz ~
12 EN/39B/06.2018 © STULZ SpA – all rights reserved
SAL
Technical name-plate
The unit can be correctly identified by the technical name-plate containing all information for its
correct use.
Each part of the split unit (internal part, external part and optional free cooling module) is identified
by its own name-plate, with a different serial number. The name-plate is located in two copies: on
the external casing of the unit (internal part, external part and optional free cooling module) and on
the cover of the electric box (internal and external unit).
An example follows (data are purely by way of example):
