Carefully note seal position before removal.
8
S30-in M. En
03-05
5 6
5 Remove stainless-steel primary air
deflector.
6 Remove both vertical protective sec-
tions lifting them by holes provided to
fix barbecue grill.
2 3
3 Rotate drum 10cm to the right, then
remove upper crosspiece.
4 Remove both bottom front refrac-
tors from stove.
4
2 Using an 8mm open-end spanner
and 8mm socket, unscrew bolt hold-
ing upper crosspiece.
Replacing lower seal between body & drum
1
1 Open door slightly. Rotate drum
10cm to the right. Lift door out of
its hinges then push it to the left.
1
2
