Stûv 30 - directions for use [en] - 07/13
Checking the condition of the seals
The 3 door seals and the drum seal
must be checked.
If any of the seals are damaged
[photo 1], have them replaced.
Checking the 3 door seals :
Open each door and check that the
seal around the entire frame is intact
[photo 2].
Checking the drum seal :
– Position the upward sliding door to
three-quarters open [photo 3] and
check the seal on your left
[photo 4].
– Lock the drum in the open-fire
position and open the door
[photo 5].
– Unlock the drum [photo 6] and
check the three remaining seals
[photos 7 and 8].
