Built-In Installation 22
Location of water filter. Water filter cartridge removal.
Water Filter Bypass Mode
A
separate bypass plug is required to bypass the water
filtration system. This bypass plug (7011209) is available
from your Sub-Zero dealer. To install the bypass plug:
1) Remove water filter cartridge by pushing the end to
disengage from the filter head. Refer to the illustration
below. Pull the filter cartridge straight out.
2) Install bypass plug by aligning it with the filter head.
Push plug in to engage with the head assembly.
When the filter or the bypass plug is removed from the
unit, the water supply to both the ice maker and the ice
and water dispenser will be shut off.
90° Door Stop
T
he doors of all built-in models open to 110°. A 90° door
stop ships with the unit and is located behind the flip-up
grille. Additional 90° door stop kits (7005865) are available
through your Sub-Zero dealer. To obtain local dealer
information, visit the showroom locator section of our
website, subzero.com.
The 90° door stop will be installed in the top hinge of the
door. To install, open the door to approximately 90°. At the
top of the door, insert the door stop down between the
door hinge and the door closer arm. Insert the screw
through the door stop and into the door as shown in the
illustration below.
90° door stop.
