- 18 -
Step Parts to remove Remarks and procedures Fasteners
10
Flywheel Remove the starting pully from the flywheel
Fit a box wrench or a socket wrench on the flywheel nut
and loosen the nut by knocking the wrench sharply with a
hammer (See Fig4-a)
NOTE:
1 Do not insert screwdriver or other object between the
flywheel blades which is a synthetic resin, otherwise
the risk of damaging the blades might be occurred
2 Knock the wrench with a hammer in a counter
clockwise direction
Remove the flywheel from the crankshaft Leave the nut
temporarily to prevent the flywheel from dropping out
Fit the flywheel puller as shown in Figure4-b and remove
the flywheel from the crankshaft by rotating the bolt
at the center in a clockwise direction(Knock the center bolt
with a hammer sometimes)
19 mm socket wrench
M14 nut : 1pc
Flywheel puller
ALUMINUM BAR
PULLER
NUT
STEP 10
HAMMER
WOODRUFF KEY
M14 FLANGE NUT : 1pc.
FLYWHEEL
- SCREWDRIVER
Fig4-a
Fig4-b
