- 21 -
Step Parts to remove Remarks and procedures Fasteners
15
Main bearing cover Remove the flange bolts of main bearing cover from
the crankcase
Remove the main bearing cover while tapping gently
around the cover using a plastic hammer or similar
tool (See Fig4-d)
Be careful not to damage the oil gauge or oil seal or
not to lose the pipe knocks
12mm box wrench
M8×55mm:6pcs
MAIN BEARING COVER
M8×55
FLANGE BOLT : 6pcs.
SPACER
CRANKCASE
STEP 15
MAIN BEARING COVER
PLASTIC HAMMER
Fig4-d
