1. Align the right side of the front cover
with the triangle mark before fixing the
cover in place.
2. Push the front cover to the right side
and shorten the bar.
3. Align the left side of the front cover
with the triangle mark before fixing the
cover in place.
& To remove the front cover
1. Push the front cover to the right side
and shorten the bar.
2. Remove the front cover.
& To remove the cover housing
1. Rewind the cover.
2. Hold down the button on the right-
hand rear quarter panel and lift up the
right-hand cover housing.
3. Remove the cover housing.
& Stowage of the cargo area
cover
The cargo area cover can be stowed in
under the cargo floor.
1. To open the lid, pull the handle up.
Interior equipment/Cargo area cover (Outback – if equipped)
– CONTINUED –
6-17
