Subaru outback 2017 - Page 566

Fuse
panel
Fuse
rating
Circuit
23 10A DRL
24 20A P/W MAIN2
25 Empty
26 10A BACK UP
27 20A WIPER DEICER
28 20A TRAIL R.FOG
29 20A P/W PASS2
30 Empty
31 7.5A SMT
32 15A SEAT HTR F
33 7.5A KEY SW
34 7.5A D_OP+B
35 20A SUN ROOF
36 Empty
37 7.5A STOP
38 7.5A EYE SIGHT
Specifications/Fuses and circuits
– CONTINUED –
12-11
