Copper and aluminum
evaporator and
condenser coils:
For extended life and
ease of repair. Coils
use seamless copper
tubing, mechanically
expanded into
aluminum plate fins.
Compressor lock-out:
Standard design
provides means of lock-
ing out A/C
compressor when
standby power
generator is operating.
Electronic control
board has 24V input
terminals to receive
lock-out signal.
Room air discharge:
Attractive, durable
grille constructed of
extruded aluminum,
52° off vertical air
discharge pattern.
Return air filter:
No tools are needed to
install or remove the
permanent electrostatic
filter constructed of
washable media.
END VIEW (LH)
UNIT WALL SLEEVE DIMENSIONS
Figure 4
Figure 3
Specifications subject to change without notice.

Suburban Dynaline 3 Specifications

General

Brand	Suburban
Model	Dynaline 3
Category	Heating System
Language	English
