Suburban Dynaline 3 User Manual

Suburban Dynaline 3 A&E Manual 12/2016 Rev.1
8
SPECIFICATIONS DYNALINE
™
3 SERIES
General Data DL3-1622 DL3-1220 DL3-091 DL3-0712
Rated heating input (BTU/h) 20,000 18,000 12,000 12,000
Rated heating output (BTU/h) 16,000 14,580 9,840 9,840
Steady state efficiency 80% 81% 82% 82%
Rated cooling capacity (BTU/h) 15,000 11,500 9,500 7,600
Sensible/Latent cooling 65/35 65/35 69/31 65/35
EER 9.5 10.4 11.2 11.6
Rated air flow: fan only (CFM)
Hi cool/low cool (CFM)
Hi heat/low heat (CFM)
340
400/330
420/340
300
390/300
410/300
260
300/250
320/260
260
300/250
320/260
Weight (Lbs.) 185 180 180 180
Cabinet Color Champagne Beige
Minimum Installation Clearances
Outside:*
Rear to nearest obstruction
Top, sides to nearest
obstruction
Centerline vent to window
3 feet
0
9"
3 feet
0
9"
3 feet
0
9"
3 feet
0
9"
Inside:
Front to nearest obstruction
Sides to nearest obstruction
Bottom to floor
(for return air)
Cabinet top to ceiling
12"**
1"
0
12"
12"**
1"
0
12"
12"**
1"
0
12"
12"**
1"
0
12"
* Clearance to ground should be noted (see installation manual).
** Obstruction must be removable for service of unit.
Electrical Data
Volts/Phase/Cycle 208/230-1-60
Min. wire size (Copper) #14 AWG #14 AWG #14 AWG #14 AWG
Protection-Fused 2-15 amp 2-15 amp 2-15 amp 2-15 amp
Protection-Circuit (HACR type) Dual - 15 amp
Unit Plug:
Amps
NEMA Rating
15 amp
6-15 P
15 amp
6-15 P
15 amp
6-15 P
15 amp
6-15 P
Receptacle:
Type
Amps
NEMA Rating
Tandem
15 amp
6-15 R
Tandem
15 amp
6-15 R
Tandem
15 amp
6-15 R
Tandem
15 amp
6-15 R
Total amps cooling/heating 7.5/1.2 5.1/1.0 3.8/1.0 3.3/1.0
Total watts cooling/heating 1550/260 1125/150 855/150 675/150
Compressor
Type Hermetic Rotary
Refrigerant type (HCFC) R410-A R410-A R410-A R410-A
Refrigerant charge 36 oz. 32 oz. 26 oz. 28 oz.
Rated Load amps 6.6 5.1 3.9 2.9
Locked rotor Amps 32 25 22 15
Rated capacity (BTU/h) 14,100 10,300 8,050 6,600
Compressor lock-out relay
(Normally closed 24V)
5VA enrush - 4V constant
Specifications subject to change without notice.
Condenser Fan DL3-1622 DL3-1220 DL3-091 DL3-0712
Fan blade diameter 12" 12" 12" 12"
Number of blades 4 4 4 4
Pitch 25º 25º 25º 25º
Condenser fan motor RPM 1,500 1,500 1,500 1,500
Full load amps 0.5 0.5 0.5 0.5
Condenser Coil
Type Copper/Aluminum
Coil Area 364 sq. inches
Rows 3 3 3 3
Fins per inch 13 13 12 12
Evaporator Coil
Type Copper/Aluminum
Coil Area 260 sq. in. 260 sq. in. 234 sq. in. 234 sq. in.
Rows 3 3 3 3
Fins per inch 11 11 11 11
Refrigerant metering Capillary
Room Air Fan Motor
Speed 2 2 2 2
RPM high/low 1500/1250 1520/1400 1260/1130 1260/1130
Full load amps 0.7 0.5 0.3 0.3
Min. wire size (60º copper) #18 AWG #18 AWG #18 AWG #18 AWG
Gas Controls and General Data
Gas (specify) Natural or LP
Burners 1 1 1 1
Ignition system: Solid-state Hot surface
High limit (fixed) 220º 220º 220º 220º
Blocked flue switch 205º 200º 200º 200º
Gas connection size 3/8" IPS 3/8" IPS 3/8" IPS 3/8" IPS
Gas connection (LH) front or rear
Blower/Evaporator
Wheel diameter 4.53" 4.53" 4.375" 4.375"
Wheel width 26" 26" 26" 26"
Air vent-manual 70 CFM 70 CFM 70 CFM 70 CFM
Required filter (1 each) 8-1/4"x30-3/4" 6"x30-3/4" 6"x30-3/4" 6"x30-3/4"
Filter type Electrostatic/washable media
