Section 3
SPECIFICATIONS
13
SULLAIR SERIES 12 AND 16 SPECIFICATIONS
DIMENSIONS
Model Series Length Width Height Weight (I)
in
mm in mm in mm lb kg
12B-40 and 50HP (STD & KT) 72 1830 48 1220 60 1524 2060 935
12B-60HP (STD & KT) 72 1830 48 1220 60 1524 2350 1066
16-60 HP (STD & KT) 72 1830 48 1220 60 1524 2590 1175
16-75 HP (STD & KT) 72 1830 48 1220 60 1524 2680 1217
ENCLOSURE (Optional) 72 1830 48 1220 62 1588 500 227
EES PACKAGE (Optional) 89 2262 48 1220 103 2618 510 259
(I) The weights shown for the Enclosure and EES packages does not include the weight of the compres-
sor package.
COMPRESSOR: 24KT MODELS STANDARD MODELS
Type Rotary Screw Rotary Screw
Standard Operating Pressure (II) 100 PSI (689kPa) (L) 100 PSI (689kPa) (L)
115 PSI (792kPa) (R) 115 PSI (792kPa) (R)
Bearing Type Anti-Friction Anti-Friction
Ambient Temperature (Max.) (III) 105ºF (40ºC) 105ºF (40ºC)
Cooling Pressurized Fluid Pressurized Fluid
Compressor Fluid Sullair 24KT Coolant Fluid SRF/400
Sump Capacity 8.0 U.S. Gallons (30 Liters) 8.0 U.S. Gallons (30.25 Liters)
(40 and 50HP) (40 and 50HP)
9.0 U.S. Gallons (34 Liters) 9.0 U. S. Gallons (34 Liters)
(60 and 75HP) (60 and 70HP)
Control Electro-Pneumatic Electro-Pneumatic
MOTOR: (60 Cycle Compressors)
24KT MODELS STANDARD MODELS
Size 40,50,60 and 75 HP 40,50,60 and 75 HP
Type C-Flanged, Open Dripproof, 460V, A.C., C-Flanged, Open Dripproof, 460V, A.C.,
Three Phase, 60 Cycles Three Phase, 60 Cycles
40ºC Maximum Ambient Temperature 40ºC Maximum Ambient Temperature
Options Available: 200V, 230V and 575V Options Available: 200V, 230V and 575V
T.E.F.C. Also Available T.E.F.C. Also Available
Starter 460V Full Voltage Magnetic 460V Full Voltage Magnetic
Options Available: 200V, 230V and 575V Options Available 200V, 230V and 575V
Speed 1770 RPM 1770RPM
(II) Special compressors are available for operating at higher pressures.
(III) Special compressors are available for operation in higher ambient temperature.
