Section 7
ILLUSTRATIONS AND PARTS LIST
43
7.3A ENGINE, COMPRESSOR AND PARTS --- CA TERPILLAR --- 185 MODELS
key part
number description number quantity
1 engine C onsul t Fa c tor y 1
2 adapter 02250084---669 1
3 compressor & part
(I)
251270---001 1
4 valve, air inlet
(II)
02250088---348 1
5 o---ring 826202---238 1
6 adapter 040292 1
7 drainlock 040061 1
8 spacer, fan 02250093---578 1
9coupling
(III)
250034---921 1
10 tee, reducing 1---1/2x1/2x1---1/2” pltd. 867506---026 1
11 bushing 250035---375 1
12 key,square class 250040---924 1
13 pin,drive 250035---041 8
14 switch, engine temp 02250084---094 1
15 tube 250011---577 1
16 sub assembly,regulator valve
(IV)
250040---047 1
17 bracket 02250078---414 1
18 elbow 02250058---275 1
19 connector 250018---428 1
20 elbow 866215---060 1
21 capscrew, hex gr5 5/8---11 x 1---1/2” pltd 829110---150 4
22 nipple,pipe 1---1/2 x 6.0 sc 40 pltd 866324---060 1
23 capscrew, hex 8.8 m8 x 60mm pltd. 828008---060 4
24 nipple,pipe 1---1/2 x cl sc 80 pltd 866424---000 1
25 nipple,pipe 3/4 x cl sc 80 pltd 866412---000 1
26 washer, lock reg 5/8” pltd. 837810---156 4
27 elbow, pipe 3/4” pltd. 866215---030 1
28 washer, sprlock metric m8 pltd. 838808---200 4
29 capscrew, hx m10 x 35 mm pltd. 828010---035 12
(Continued on Page 45)
(I)
There is an exchange program whereby a remanufactured compressor unit can be obtained
from Sullair distri butors or the factory at less cost than the owner could repair the unit. For
information regarding the unit exchange program, contact your nearest Sullair representative
or the Sullair Corporation.
The shaft seal is not considered part ofthe compressor unit in regard to the two year warranty.
The normal Sullair parts warranty applies. For shaft seal repairs consult factory.
(II)
For maintenance on inlet valve 02250088---348, order repair kit no.250019---451 .
(III)
For maintenance on coupling 250034---921, order repair kit no.250041---801.
(IV)
SEE SECTION 7.7C.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
