Section 7
ILLUSTRATIONS AND PARTS LIST
73
7.5B RADIATOR & COMPRESSOR FLUID SYSTEM --- CUMMINS --- ALL MODELS (continued)
key part
number description number quantity
33 hose 02250093---813 1
34 cable(ft) 241380 2
35 hose 02250093---791 1
36 washer, pl b r 3/8” pltd 838206---071 2
37 screw, hx ser wash 5/16 x 3/4 pltd 829705---075 2
38 screw, hx ser wash 5/16 x 1/2 pltd 829705---050 8
39 nut,hex flanged 5/16 pltd 825305---283 2
40 capscr, hex gr5 1/4---20 x 3/4 pltd 829104---075 4
41 nut,hex locking 3/8 pltd 825506---198 2
42 capscrew, hx gr 5 3/8 x 1” pltd 829106---100 2
43 elbow, 37fl 90m 3/4 x 3/4” 860212---075 2
44 washer, lock reg 1/4” pltd 837804---062 4
45 washer, pl b r 1/4” pltd 838204---071 4
47 filter, fluid
(I)
02250081---585 1
48 valve, thermal
(II)
409193 1
49 nipple,pipe 3/4 x cl sc 80 pltd 866412---000 1
50 nipple,pipe 3/4 x 2 sc 40 pltd 866312---020 1
51 tee,straight 3/4” 150# pltd 866815---030 1
52 connector,37f/mpt 3/4 x 3/4” 860112---075 2
(I)
For maintenance on fluid filter no. 02250081---585, order replacement kit no. 250025---524.
(II)
For maintenance on thermal valve no. 409193, order repair kit no. 250017---340.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
