Section 7
ILLUSTRATIONS AND PARTS LIST
61
7.4B ENGINE, COMPRESSOR AND PARTS --- CUMMINS --- 185H MODELS (continued)
key description: engine, compressor & parts part
number (continued) number quantity
3 2 engine Consul t Fac tor y 1
33 connector 250018---428 1
34 elbow 866215---060 1
35 capscrew, hex gr5 5/8---11 x 1---1/2” pltd 829110---150 4
36 nipple,pipe 1---1/2 x 6.0 sc 40 pltd 866324---060 1
37 capscrew, hx 8.8 m10 x 75 828010---075 4
38 nipple,pipe 1---1/2 x cl sc 80 pltd 866424---000 1
39 nipple,pipe 3/4 x cl sc 80 pltd 866412---000 1
40 washer, lock reg 5/8” pltd 837810---156 4
41 elbow, pipe 3/4 pltd 866215---030 1
42 washer, sprlock metric m10 838810---220 4
43 capscrew, ferry 3/8---16 x 1 1/4 867306---125 7
44 capscrew, ferry hd 3/8 x 1 1/2” plt 867306---150 8
45 nipple,pipe 1/8 x cl sc 80 866402---000 1
46 connector 02250097---138 1
47 washer, lock m10 838810---220 12
48 washer, pl---b reg. 7/16” 838207---071 12
49 sub assembly,control orifice
(IV)
02250091---556 1
50 capscrew, hex metric m10 x 35 828010---035 12
51 spacer, fan 02250099---437 1
52 bushing, reducing 1/2 x 1/4 867102---010 1
53 capscrew, h x 8.8 m8 x 25 828008---025 2
description: speed cylinder --- ITEM 6
1 rod 250011---590 1
2 cylinder, speed 250021---405 1
3 joint, ball 250011---597 1
4 elbow, 1/4” tube x 1/8” npt 250018---429 1
5 joint, ball 250011---578 1
6 nut,hex jam rh unfin 1/4” 824604---164 2
7 nut,hex jam lh unfin 1/4” 824704---164 1
8 spring 250022---782 1
9 washer 837204---071 1
(IV)
SEE SECTION 7.7C.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
