Sullair 20/12 Series User Manual

Section 7
ILLUSTRATIONS AND PARTS LIST
39
7.4 AIR INLET SYSTEM
key part
number description number quantity
1 gasket, 81/2” x 101/2” x 1/32” 040422 2
2 valve, butterfly 8” (500--750 CFM) 040336 1
S
valve, butterfly 8” (800--960 CFM) 040338 1
3 lever , inlet valve 250026--787 1
4 adapter, air inlet (500--750 CFM) 012897 1
S
adapter, air inlet (800--960 CFM) 250001--083 1
5 capscrew, hex gr5 3/4”--10 x 3” 828612--300 8
6 elbow, rubber 90
_
reducing 8” x 7” 245796 1
7 clamp, hose 8” 043598 1
8 clamp, hose 7” 041992 6
9 duct, air inlet aluminum 7” x 46” 250020--994 1
10 elbow, rubber 90
_
x 7” 046078 1
11 duct, aluminum 7”od x 9” 232591 1
12 hose, hump 7” 041917 1
13 capscrew, hex gr5 5/16”--18 x 11/2” 828605--150 1
14 nut, hex 3/8”--16 824206--337 4
15 support, air inlet filter 250000--826 1
16 capscrew, hex gr5 3/8”--16 x 1” 828606--100 4
17 band, mounting 16” 044248 2
18 filter, air assembly (500--630 CFM)
(I)
046956 1
S
filter, air assembly(800--960 CFM)
(II)
048456 1
S
filter, air assembly (750 CFM)
(III)
046020 1
19 cap, air inlet 7” 046307 1
(I)
For maintenance on air filter no. 046956 (500--630 CFM) order replacement element no. 046968
(primary), and 046981 (secondary).
(II)
For maintenance on air filter no. 048456 (800--960 CFM) order replacement element no. 048462
(primary), and 048463 (secondary).
(III)
For maintenance on air filter no. 046020 (750 CFM) order replacement element no. 046299 (primary),
and 047523 (secondary).
PLEASE NOTE: W HEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
