Sullair 20/12 Series User Manual

Section 7
ILLUSTRATIONS AND PARTS LIST
41
7.5 COOLING AND LUBRICATION SYSTEM
key part
number description number quantity
1 elbow, reducing 2” x 11/2” 806808--150 3
2 nipple, pipe 2” x close 822232--000 2
3 cooler , fluid (200HP thru 300HP) 048085 1
S
cooler , fluid (350HP thru 400HP) 408368 1
4 u--bolt, 3/8” x 2” pipe 829006--200 4
5 elbow, pipe 90
_
11/2” 806530--060 17
6 nipple, pipe 11/2” x close 822224--000 6
7 union, pipe 11/2” 805730--060 5
8 elbow, pipe 45
_
11/2” 806430--060 1
9 nipple, pipe 11/2” x 10” 822224--100 1
10 nipple, pipe 11/2” x 211/2” 822224--215 1
11 nipple, pipe 11/2” x 7” 822224--070 3
12 nipple, pipe 11/2” x 12” 822224--120 1
13 nipple, pipe 11/2” x 131/2” 822224--135 1
14 valve, thermal
(I)
250001--456 1
15 valve, fluid stop
(II)
250038--489 1
16 union, pipe 2” 805730--080 1
17 tee, pipe 11/2” 806630--060 1
18 nipple, pipe 11/2” x 9” 822224--090 1
19 nipple, pipe 11/2” x 31/2” 822224--035 1
20 bracket, fluid filter support 250002--445 1
21 filter, fluid -- main
(III)
045111 1
22 nipple, pipe 11/2” x 141/2” 822224--145 1
(I)
For maintenance on thermal valve no. 250001--456, order repair kit no. 250001--349
(element), quad ring seal replacement no. 046425, and gasket replacement no. 049812.
(II)
For maintenance on fluid stop valve no. 250038--489, order repair kit no. 250038--494
(o--rings and poppet) and repair kit no. 250038--490 (piston and parts).
(III)
For maintenance on main fluid filter no. 045111, order replacement kit no. 001094 (element), and re-
placement kit no. 001132 (seal).
PLEASE NOTE: W HEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
