Section 7

ILLUSTRATIONS AND PARTS LIST

7.6 COOLER ASSEMBLY

key part

number description number quantity

1 support, cooler 250020--736 2

2 cooler , fluid (200HP thru 300HP) 048085 1

cooler , fluid (350HP thru 400HP) 408368 1

3 panel, top/bottom 250020--738 2

4 panel, cooler side -- left hand 250020--740 1

5 bracket, cooler -- left hand 250021--004 1

bracket, cooler -- right hand 250021--003 1

6 aftercooler, (200HP thru 300HP) 250008--938 1

aftercooler, (350HP thru 400HP) 406722 1

7 angle, aftercooler support 250020--737 4

8 panel, cooler side -- right hand 250020--739 1

9 panel, Venturi 42” (200HP thru 300HP) 250001--202 1

panel, Venturi 48” (350HP thru 400HP) 049998 1

10 fan, 42” (200HP thru 300HP) 250004--688 1

fan, 48” (350HP thru 400HP) 049986 1

11 guard, fan 42” 241283 1

guard, fan 48” 241347 1

12 motor, 15HP (200HP thru 300HP) 050387 1

motor, 20HP (350HP thru 400HP) 050428 1

13 support, fan motor 250000--825 1

PLEASE NOTE: W HEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
