Section 7
ILLUSTRATIONS AND PARTS LIST
47
7.7 DISCHARGE SYSTEM (continued)
key part
number description number quantity
31 support, water separator 250000--844 1
32 separator, water 406746 1
33 trap, separator 016586 1
34 elbow, pipe 45
_
3/4” 806430--030 1
35 union, pipe 3/4” 805730--030 1
36 trap, auto 3/4” 250006--639 1
37 connector, tube--m 1/4” x 1/4” 810204--025 4
38 glass, sight 046559 1
39 orifice 022033 1
40 nipple, pipe 1/4” x close 822204--000 2
41 strainer, y--line 1/4”
(IV)
240686 1
42 rod, threaded 3/4”--10 x 36” 222918 1
43 plate, separator 223337 1
44 gasket, receiver/separator cover 151/2” 223509 1
S
gasket, receiver/separator cover 16” 250006--536 1
(IV)
For maintenance on y--line strainer no. 240686, order repair kit no. 240686.
PLEASE NOTE: W HEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
