Sullair 20/12 Series User Manual

Section 7
ILLUSTRATIONS AND PARTS LIST
49
7.8 INSTRUMENT PANEL AND PARTS
key part
number description number quantity
1 gauge, vacuum 250003--797 1
2 gauge, temperature 045858 1
3 gauge, pressure 048061 2
4 nameplate, Sullair 250035--063 1
5 indicator 046551 1
6 indicator, differential pressure 042148 1
7 fastener , suregrip 041516 4
8 nameplate, Sullair 040052 1
9 capscrew, hex gr5 3/8”--16 x 11/2” 828606--150 4
10 washer, springlock 3/8” 837606--125 8
11 isolator, vibration 040091 4
12 nut, hex 3/8”--16 828206--337 4
13 connector, tube--f 1/4” x 1/4” 810104--012 4
14 tee, tube 1/4” x 1/8” 811004--012 1
15 connector, tube--m 1/4” x 1/8” 813604--125 1
16 hose, nylon 1/4” (ft.) 842215--004 7 feet
17 panel, instrument 250006--975 1
PLEASE NOTE: W HEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
