Sullair 20/12 Series User Manual

Section 7
ILLUSTRATIONS AND PARTS LIST
51
7.9 CONTROL SYSTEM
key part
number description number quantity
1 gauge, pressure 2” 250005--185 2
2 elbow, tube--m 1/4” x 1/4” 810504--025 10
3 tubing, steel 1/4” (ft.) 841015--004 25 feet
4 orifice, pipe plug 1/4” 232874 1
5 cross, pipe 1/4” 806330--010 1
6 nipple, pipe 1/4” x close 822204--000 12
7 valve, pressure regulator
(I)
048354 2
8 elbow, pipe 90
_
1/4” 806530--010 1
9 valve, regulator 400 PSIG (2758kPa)
(II)
048059 1
10 tee, pipe 1/2” 806630--020 3
11 nipple, pipe 1/2” x close 822208--000 2
12 bushing, reducing 1/2” x 1/4” 807602--010 2
13 tee, pipe 1/4” 806630--010 2
14 connector, tube--m 1/4” x 1/4” 810204--025 10
15 valve, pneumatic
(III)
045116 1
16 silencer , air 1/2” 250023--532 1
17 valve, in--line check 045244 3
18 valve, solenoid 3--way
(IV)
250038--666 1
19 valve, solenoid 3--way
(V)
407390 1
20 rod end, spherical 5/16” -- left hand 042004 1
21 rod, Sullicon Control 250028--170 1
22 cylinder , air control
(VI)
250016--990 1
23 rod end, spherical 5/16” -- right hand 040136 1
24 screw , machine hex 3/8”--16 x 2” 830106--200 1
25 nut, hex 3/8”--16 824206--337 7
26 bracket, control stop 020864 1
27 lever, control 011084 1
(continued on Page 53)
(I)
For maintenance on pressure regulator valve no. 048354, order repair kit no. 048410.
(II)
For maintenance on regulator valve no. 048059, order repair kit no. 048409.
(III)
For maintenance on pneumatic valve no. 045116, order repair kit no. 047524.
(IV)
For maintenance on solenoid valve no. 250038--755, order repair kit no. 250038--676,
and coil replacement no. 250038--730.
(V)
For maintenance on solenoid valve no. 407390, order repair kit no. 042246.
(VI)
For maintenance on air control cylinder no. 250016--990, order repair kit no. 250014--573.
PLEASE NOTE: W HEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
