Section 7

ILLUSTRATIONS AND PARTS LIST

7.9 CONTROL SYSTEM (continued)

key part

number description number quantity

28 screw , machine hex 5/16” -- 24 x 2” 831105--200 1

29 screw , machine shoulder 3/8”--16 x 2” 830506--200 1

30 body, control 021635 1

31 pin, cotter 1/16” x 3/4” 827101--075 1

32 yoke, rod end 1/4”--28 040138 1

33 pin, yoke 1/4” 040065 1

34 plunger 020094 1

35 seal, cup 042538 1

36 diaphragm, Sullicon 250020--028 1

37 spring, control 250006--526 1

38 bolt, adjusting Sullicon spring 250009--134 1

39 washer, back--up 021172 1

40 screw , sealing 1/4”--28 x 3/4” 041264 1

41 cover , control 021654 1

42 plug, pipe 1/4” 807800--010 1

43 bracket, Sullicon (6” inlet) 250031--765 1

bracket, Sullicon (8” inlet) 250031--766 1

44 control, Sullicon (less bracket)

(VII)

011682--003 1

(VII)

For maintenance on Sullicon Control 011682--003, order repair kit no. 250020--353.

PLEASE NOTE: W HEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
