Sullair 20/12 Series User Manual

Section 7
ILLUSTRATIONS AND PARTS LIST
57
7.11 UNIT TUBING
key part
number description number quantity
1 plug, pipe 1/2” 807800--020 11
2 manifold, bearing 227238 1
3 elbow, hose--m 1/2” x 1/2” 860208--050 3
4 elbow, hose--m 5/8” x 1/2” 860210--050 1
5 connector, hose 3/8” x 1/2” 860106--050 2
6 hose, hydraulic 1/2” x 32” 249608--008 1
7 hose, hydraulic 5/8” x 11” 249610--005 1
8 hose, hydraulic 3/8” x 40” 249606--006 1
9 hose, hydraulic 3/8” x 33” 249606--005 1
10 nipple, pipe 1” x close 822216--000 1
11 bushing, reducing 11/4” x 1” 807605--040 1
12 capscrew, hex 3/8” x 3/4” 828205--075 4
13 washer, regular 5/16” 837205--071 4
14 bracket, filter 017211 1
15 capscrew, hex 5/8” x 11/2” 828210--150 3
16 filter, bearing
(I)
250019--296 1
17 nipple, close 11/4” x 31/2” 822220--035 1
18 hose, hydraulic 1/2” x 13” 249608--006 1
19 manifold, injection 227239 1
20 elbow, hose 45
_
1/2” x 1/2” 860008--050 1
21 hose, hydraulic 1/2” x 24” 249608--005 1
22 plug, pipe 1/4” 807800--015 5
23 connector, hose 5/8” x 3/8” 860110--038 1
24 plug, pipe 21/2” 807800--100 1
25 elbow, hose 1/2” x 3/4” 860208--075 1
26 elbow, hose 3/8” x 1/4” 860206--025 1
27 hose, hydraulic 3/8” x 13” 249606--007 1
28 tee, hose 3/8” x 1/4” 861706--025 1
29 valve, pressure relief 040647 2
30 tee, pipe reducing 11/4” x 1” x 1” 806705--044 1
31 nipple, pipe 11/4” x close 822220--000 1
32 connector, hose 1/2” x 1/4” 860108--025 1
33 hose, hydraulic 1/2” x 29” 249608--007 1
34 connector, hose 3/8” x 1/4” 860106--025 1
(continued on Page 59)
(I)
For maintenance on bearing filter no. 250019--296, order repair kit no. 602568--001.
PLEASE NOTE: W HEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
