Section 7
ILLUSTRATIONS AND PARTS LIST
59
7.11 UNIT TUBING (continued)
key part
number description number quantity
35 gasket, air inlet 028078 1
36 adapter , air inlet 013410 1
37 capscrew, ferry head gr8 3/4” x 11/2” 828412--150 8
38 coupling, flexible 31/2” 040356 1
39 gasket, flexible 040771 2
40 plug, pipe 1” 807800--040 1
41 gasket, air outlet 028077 1
42 capscrew, ferry head gr8 3/8” x 1/2” 828406--150 4
43 adapter , air outlet 250022--747 1
44 elbow, 45
_
860020--100 1
45 hose, hydraulic 1” x 38” 249610--005 1
46 elbow, 90
_
860220--100 1
47 tee, pipe 1/4” 806630--010 1
48 nipple, pipe 1/4” x close 822204--000 1
49 elbow, 90
_
1/2” x 1/4” 860208--025 1
PLEASE NOTE: W HEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
