Section 7
ILLUSTRATIONS AND PARTS LIST
97
7.14A INSTRUMENT PANEL AND PARTS -- 185H AND 210H CATERPILLAR ( STANDA RD GAUGE)
key part
number description number quantity
1 gauge, pressure air 0---300 2” 02250044---361 1
2 hour---meter, 12---24vdc 10000hr 2” 02250050---517 1
3 tee, m run 3/8”tube x 1/4”npt 02250099---615 2
4 elbow, 90 3/8”tube x 1/4”npt m 02250099---626 2
5 tube, nylon .375”od x .050w black 02250099---630 2 ft
6 controller, 185/375 shutdown
module (ssam) 02250126---682 1
7 lense, cliplite led 02250129---189 1
8 panel, instrument plastic ssam 02250129---190 1
9 decal, dual pressure 185---375 ssam 02250130---630 1
10 decal, starting aid 185---375 cat 02250130---631 1
11 decal, group std panel (ssam) 02250131---485 1
12 switch, engine ignition 12---volt 02250132---883 1
13 valve, ball 2---way 1/4”npt 02250136---999 2
14 elbow, 90 f 3/8”tube x 1/4”npt 02250137---033 1
15 cover, access ssam molded abs 02250137---265 1
16 harness, wiring 210h---260 cat t2 02250154---334 1
17 switch, starter push---button 040038 1
18 screw, tc---f rd hd #6---32 x 1/2 835700---050 2
19 washer, pl---b reg pltd #6 838200---045 2
20 bushing, red pltd 1/4 x 1/8 867100---005 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
