Section 7
ILLUSTRATIONS AND PARTS LIST
65
7.5 AIR INLET VALVE ASSEMBLY -- 260 JOHN DEERE AND CATERPILLAR
key part
number description number quantity
1 control vlv sa 250035---309 1
2 cast body--- painted iron p/n/alum. 250039---716 1
3 disc seal 250039---717 1
4 hex ret. ca p 250039---669 1
5 spring for piston 250039---718 1
6 piston 250039---670 1
7 piston o---ring viton 250039---671 1
8 spring for cont. vlv. 250039---719 1
9 retaining ring (split) 250039---720 1
NOTE 1: For maintenance on inlet valve (185H, 210H John Deere), order repair kit no. 02250109---684.
NOTE 2: O---ring no. 826202---238 is used to seal off the inlet valve assembly with the compressor unit.
NOTE 3: For maintenane on inlet valve (260 John Deere), order repair kit no. 250019---451, or spring replace-
ment kit no. 250029---315.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
To Next Page
