ILLUSTRATIONS AND PARTS LIST
77
8.13 WATER PIPING- 40HP/ 30KW WATER-COOLED
key part
number description number quantity
1 tee, sae/npt oil return 02250085-979 1
2 adapter, sae 1 5/16 x 1 5/16-12 02250086-022 1
3 filter, fluid 1 5/8 sae str thrd co (I) 02250136-535 1
4 connector, sae x orfs 0.75” 02250099-765 1
5 elbow, 90 sae x orfs .75” 02250099-766 3
6 connector,sae x orfs .75” 02250135-568 2
7 hose, medium pressure orfs 1”x 18” 02250141-106 1
8 hose, medium pressure orfs 1” x 36” 02250141-407 1
9 hose, medium pressure orfs 1”x 47 02250141-408 1
10 valve, water regulator 1/2” 041265 1
11 switch, pressure n.o. 10 psi 250017-992 1
12 elbow, 90 1/4”tube x 1/8”npt 250018-429 1
13 elbow, 1/4” tube x 1/4” npt 250018-430 1
14 clamp, tubing 1-1/8” dia 250025-636 1
15 tubing, nylon 3/4” 250039-353 1
16 connector, male plastic tubing 3/4x3/4 250039-357 2
17 union, pipe galv 1/2 802315-020 1
18 nut, hex f pltd 5/16-18 825305-283 1
19 screw, hex ser washer 1/4-20 x 1/2 829704-050 2
20 screw, hex ser washer 5/16-18 x 3/4 829705-075 1
21 locknut, conduit 1/2 847200-050 1
22 elbow, pipe-90m 3/4 x 1/2 860512-050 1
23 elbow, pipe 90 deg plt 1/2” 866215-020 1
24 elbow, pipe 90 deg plt 3/4” 866215-030 1
25 nipple, pipe-xs plt 1/2 x cl 866408-000 1
26 plug, pipe 1/4” 3000# stl plt 866900-010 1
27 nipple, pipe-hx pltd 1/2 x 1/2 868508-050 1
28 nipple, pipe-hx pltd 3/4 x 3/4 868512-075 1
29 nipple, pipe-hx pltd 1 x 1 868516-100 1
30 elbow, red 1 x 3/4 150# plt 869204-030 1
31 reducer, str thrd viton 1 1/4 x 3/4 870020-012 2
(I) For maintenance on fluid filter no. 02250136-535, order replacement element no. 250025-525.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
