Section 3
SPECIFICATIONS
15
3.1 LS-100 SPECIFICATIONS
LS-100 SERIES 60 Hz
MODEL HP/KW CAPACITY LENGTH (I) WIDTH HEIGHT(II) WEIGHT MOTOR
(ACFM/M
3
/MIN) (IN/MM) (IN/MM) (IN/MM) (LB/KG) ENCLOSURE
L 25/18 119/3.37 55.2/1397 33.7/856 38.8/986 990/450 ODP
(100 psig/ 25/18 119/3.37 60.2/1529 33.7/856 38.8/986 990/450 TEFC
6.9 bar) 30/22 134/3.79 56.7/1440 33.7/856 38.8/986 1015/460 ODP
30/22 134/3.79 60.2/1529 33.7/856 38.8/986 1015/460 TEFC
40/30 169/4.79 58.6/1488 33.7/856 38.8/986 1115/506 ODP
40/30 169/4.79 63.4/1610 33.7/856 38.8/986 1140/517 TEFC
H 25/18 106/3.00 55.2/1397 33.7/856 38.8/986 990/450 ODP
(125 psig/ 25/18 106/3.00 60.2/1529 33.7/856 38.8/986 990/450 TEFC
8.6 bar) 30/22 127/3.60 56.7/1440 33.7/856 38.8/986 1015/460 ODP
30/22 127/3.60 60.2/1529 33.7/856 38.8/986 1015/460 TEFC
40/30 163/4.62 58.6/1488 33.7/856 38.8/986 1115/506 ODP
40/30 163/4.62 63.4/1610 33.7/856 38.8/986 1140/517 TEFC
HH 25/18 95/2.69 55.2/1397 33.7/856 38.8/986 990/450 ODP
(150 psig/ 25/18 95/2.63 60.2/1529 33.7/856 38.8/986 990/450 TEFC
10.3 bar) 30/22 111/3.14 56.7/1440 33.7/856 38.8/986 1015/460 ODP
30/22 111/3.14 60.2/1529 33.7/856 38.8/986 1015/460 TEFC
40/30 147/4.16 58.6/1488 33.7/856 38.8/986 1115/506 ODP
40/30 147/4.16 63.4/1610 33.7/856 38.8/986 1140/517 TEFC
XH 25/18 85/2.41 55.2/1397 33.7/856 38.8/986 990/450 ODP
(175 psig/ 25/18 85/2.41 60.2/1529 33.7/856 38.8/986 990/450 TEFC
10.3 bar) 30/22 103.5/2.93 56.7/1440 33.7/856 38.8/986 1015/460 ODP
30/22 103.5/2.93 60.2/1529 33.7/856 38.8/986 1015/460 TEFC
40/30 130/3.68 58.6/1488 33.7/856 38.8/986 1115/506 ODP
40/30 130/3.68 63.4/1610 33.7/856 38.8/986 1140/517 TEFC
LS-100 SERIES 50 Hz
MODEL HP/KW CAPACITY LENGTH (I) WIDTH HEIGHT(II) WEIGHT MOTOR
(ACFM/M
3
/MIN) (IN/MM) (IN/MM) (IN/MM) (LB/KG) ENCLOSURE
L 25/18 110/3.11 55.2/1397 33.7/856 38.8/986 990/450 ODP
(100 psig/ 25/18 110/3.11 60.2/1529 33.7/856 38.8/986 990/450 TEFC
6.9 bar) 30/22 135/3.82 56.7/1440 33.7/856 38.8/986 1015/460 ODP
30/22 135/3.82 60.2/1529 33.7/856 38.8/986 1015/460 TEFC
40/30 167/4.73 58.6/1488 33.7/856 38.8/986 1115/506 ODP
40/30 167/4.73 63.4/1610 33.7/856 38.8/986 1140/517 TEFC
H 25/18 101/2.86 55.2/1397 33.7/856 38.8/986 990/450 ODP
(125 psig/ 25/18 101/2.86 60.2/1529 33.7/856 38.8/986 990/450 TEFC
8.6 bar) 30/22 121/3.43 56.7/1440 33.7/856 38.8/986 1015/460 ODP
30/22 121/3.43 60.2/1529 33.7/856 38.8/986 1015/460 TEFC
40/30 151/4.28 58.6/1488 33.7/856 38.8/986 1115/506 ODP
40/30 151/4.28 63.4/1610 33.7/856 38.8/986 1140/517 TEFC
HH 25/18 89/2.52 55.2/1397 33.7/856 38.8/986 990/450 ODP
(140 psig/ 25/18 89/2.52 60.2/1529 33.7/856 38.8/986 990/450 TEFC
19.7 bar) 30/22 108/3.06 56.7/1440 33.7/856 38.8/986 1015/460 ODP
30/22 108/3.06 60.2/1529 33.7/856 38.8/986 1015/460 TEFC
40/30 141/3.99 58.6/1488 33.7/856 38.8/986 1115/506 ODP
40/30 141/3.99 63.4/1610 33.7/856 38.8/986 1140/517 TEFC
XH 25/18 81/2.29 55.2/1397 33.7/856 38.8/986 990/450 ODP
(175 psig/ 25/18 81/2.29 60.2/1529 33.7/856 38.8/986 990/450 TEFC
12 bar) 30/22 97/2.75 56.7/1440 33.7/856 38.8/986 1015/460 ODP
30/22 97/2.75 60.2/1529 33.7/856 38.8/986 1015/460 TEFC
40/30 126/3.57 58.6/1488 33.7/856 38.8/986 1115/506 ODP
40/30 126/3.57 63.4/1610 33.7/856 38.8/986 1140/517 TEFC
(I) For water-cooled (open) model, add 1.5 in/ 38mm to length, and 1 in/ 25 mm to height.
(II) An additional length of 4 in./102mm is needed for servicing the separator; 9 in./229mm for enclosure
models.
(Continued on page 16)
