Section 3
SPECIFICATIONS
16
COMPRESSOR: STANDARD MODELS
Type: Rotary Screw
Standard Operating Pressure (IV): 100 psig (6.9 bar) (L) 150 psig (10.3 bar) (HH)
125 psig (8.6 bar) (H) (XH) 175 psig (12 bar) (XH)
Bearing Type: Anti-Friction
Ambient Temperature (Max.) (V): 105ºF (41ºC)
Cooling: Pressurized Fluid
Compressor Fluid: Sullair Sullube
Sump Capacity: 3.0 U.S. gallons (11.4 liters)
Control: Electro-Pneumatic
Supervisor II (optional)
MOTOR (VI): STANDARD MODELS
Size: 25, 30 and 40HP
Type: C-Flanged, Open Dripproof, Premium Efficiency
Three Phase, 230/460 60 Hz, 380/415 50 Hz
40ºC Maximum Ambient Temperature
Options Available: 200V and 575V
T.E.F.C. Also Available: IP54
Starter: Full Voltage Magnetic or Wye Delta
Options Available: 200V and 575V
Speed: 60 Hz: 1770 RPM
50 Hz: 1475 RPM (except 40L, 40H and 40HH = 2950 RPM)
40L, 40H, 40HH, 40XH: 1475RPM
(IV) Special compressors are available for operation at higher pressures.
(V) Special compressors are available for operation in higher ambient temperature.
(VI) Multi-frequency and voltage motors are used. The compressors must be used only with the specified
electrical frequency and voltage.
3.2 LUBRICATION GUIDE- STANDARD
Refer to Figure 3-1 for location of fluid fill port. For
best value and longest uninterrupted service, the
LS-100 Series compressors are factory filled and
tested with Sullube lubricant.
Mixing of other lubricants within the compressor
unit will void all warranties
If, due to availability or other reasons, other fluids
are required, follow Lubrication Guide 3.4 below.
LS-100 SERIES (CONTINUED)
ENCL HP/KW CAPACITY LENGTH (I) WIDTH HEIGHT(II) WEIGHT MOTOR
MODEL (ACFM/M
3
/MIN) (IN/MM) (IN/MM) (IN/MM) (LB/KG) ENCLOSURE
25-30 HP/ - - 60.0/1524 36.0/914 42.0/1067 (III) ODP
18-22 KW - - 66.0/1676.4 36.0/914 42.0/1067 (III) TEFC
40 HP/
30 KW - - 66.0/1676.4 36.0/914 42.0/1067 (III) ODP/TEFC
(I) For water-cooled (open) model, add 1.5 in/ 38mm to length, and 1 in/ 25 mm to height.
(II) An additional length of 4 in./102mm is needed for servicing the separator; 9 in./229mm for enclosure models.
(III) Add 250 lbs/ 113.4 kgs for the enclosure to the total package weight.
