Section 8
ILLUSTRATIONS AND PARTS LIST
91
8.19 ENCLOSURE- 25-30HP/ 18-22KW AIR-COOLED (ODP)
key part
number description number quantity
1 seal, door extruded sponge 013978 4 ft.
2 frame, enclosure assy. 014790 1
3 strip, weather 1” x 1/8” foam 02250058-345 55 ft.
4 lch. adj. trigger-lock blk es 02250094-632 4
5 panel, access door 33” x 33” 02250100-067 2
6 panel, assembly roof 36” x 30” 10ser 02250103-206 2
7 panel, instrument e/m ls-10 l.f. canopy 02250104-191 1
8 seal, dust ls100 encl 02250105-900 4
9 panel, encl right rear ls10 02250141-499 1
10 panel, enclosure-rh w/insulation 02250141-734 2
11 panel, enclosure - lh w/insulation 02250141-735 1
12 panel, access ls10lf e/m siidlx w/insulat 02250141-737 1
13 panel, enclosure ls10ac cooler end 02250141-767 1
14 shroud, clr cnpy ls10-25hp odp 02250143-886 1
15 shroud, clr cnpy ls10-30hp odp 02250144-098 1
16 gasket, trim - canopy shrd edge ls10 02250144-124 8
17 panel, enclosure center sect. 224585 4
18 trim, canopy edge 7.5/10hp 250034-157 4
19 nut, hex f pltd 5/16-18 825305-283 28
20 capscr, hex gr5 1/4-20 x 1 829104-100 2
21 screw, hex ser washer 5/16-18 x 3/4 829705-075 44
22 washer, spr lock reg pltd 1/4 837804-062 2
23 nut, retainer 5/16-18 .092 861405-092 4
24 nut, retainer u 5/16-18 .140 861505-140 12
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
