Sullair LS16 - Section 3 Specifications; Table of Specifications

Section 3
SPECIFICATIONS
15
3.1 TABLE OF SPECIFICATIONS
LS--12 SERIES 60 Hz
MODEL (I) HP/KW CAPACITY LENGTH WIDTH HEIGHT(II) WEIGHT(III) dBA(IV)
(ACFM/M
3
/MIN) (IN/MM) (IN/MM) (IN/MM) (LB/KG) w/ encl./
w/o encl.
(Air--cooled)
L 50/37 235/6.65 72/1830 48/1220 60/1524 2060/934 80/87
H 50/37 212/6.00 72/1830 48/1220 60/1524 2060/934 80/87
60/45 254/7.19 72/1830 48/1220 60/1524 2350/1066 80/87
HH 50/37 187/5.30 72/1830 48/1220 60/1524 2060/934 80/87
60/45 227/6.43 72/1830 48/1220 60/1524 2350/1066 80/87
XH 50/37 154/4.36 72/1830 48/1220 60/1524 2060/934 80/87
60/45 179/5.07 72/1830 48/1220 60/1524 2350/1066 80/87
LS--12 SERIES 50 Hz
MODEL (I) HP/KW CAPACITY LENGTH WIDTH HEIGHT(II) WEIGHT(III) dBA(IV)
(ACFM/M
3
/MIN) (IN/MM) (IN/MM) (IN/MM) (LB/KG) w/ encl./
w/o encl.
(Air--cooled)
H 50/37 211/5.97 72/1830 48/1220 60/1524 2060/934 80/87
HH 50/37 173/4.90 72/1830 48/1220 60/1524 2060/934 80/87
60/45 205/5.80 72/1830 48/1220 60/1524 2350/1066 80/87
XH 50/37 150/4.25 72/1830 48/1220 60/1524 2060/934 80/87
60/45 182/5.15 72/1830 48/1220 60/1524 2350/1066 80/87
LS--16 SERIES 50 Hz
MODEL (I) HP/KW CAPACITY LENGTH WIDTH HEIGHT(II) WEIGHT(III) dBA(IV)
(ACFM/M
3
/MIN) (IN/MM) (IN/MM) (IN/MM) (LB/KG) w/ encl./
w/o encl.
(Air--cooled)
H 60/45 258/7.31 72/1830 48/1220 60/1524 2590/1175 82/85
75/55 312/8.83 72/1830 48/1220 60/1524 2680/1216 82/85
HH 60/45 229/6.48 72/1830 48/1220 60/1524 2590/1175 82/85
75/55 263/7.45 72/1830 48/1220 60/1524 2680/1216 82/85
XH 60/45 195/5.52 72/1830 48/1220 60/1524 2590/1175 80/87
75/55 247/6.99 72/1830 48/1220 60/1524 2680/1216 82/85
(I) Includes standard and 24KT. Rated pressure designations appearing after model number are as follows:
“L” -- 100 psig /6.9 bar “H” -- 115 psig/7.9 bar “HH” --140 psig/9.7 bar “XH”--175 psig/12 bar
Maximum pressure is rated pressure and 10 psig (0.7 bar).
(II) An additional length of 4 in./102 mm is needed for servicing the separator; 9 in./229 mm for enclosure models.
(III) Add 1450 lbs/658 kg for enclosure models.
(IV) Ratings for dBA at one meter.
