9.4 AIR INLET SYSTEM
key part
number description number quantity
1 valve, assembly inlet 6.50" (I) 02250141-182 1
2 orf, .040 1/4fnpt x 1/4mnpt 02250091-395 1
3 tube, 7" x 6.5" w/3/8" conn 02250120-368 1
4 pipe, 6" aluminum 150# (m) 02250126-548 1
5 hose, hump 7" 041917 2
6 clamp, hose 7" 041992 9
7 band, mounting 16” 044248 2
8 rubber elbow 7 i.d. x 90 deg. 046078 2
9 cap, air inlet 7” 046307 1
10 filter, inlet optimalair 16”odx7”inlt (II) 048456 1
11 tube, alum air inlet 7”od x 9”lg 232591 2
12 gasket, 6” 125# flg full face (III) 242437-012 2
13 support, air inlet filter 250000-826 1
14 nipple, pipe-xs 316s 1/4 x cl 250019-142 3
15 elbow, pipe 90 deg 1/8” 803515-005 1
16 connector, tube-m 1/4 x 1/8 813604-125 1
17 nipple, pipe-xs galv 3/8 x cl 823206-000 2
18 nut, hex pltd 1/2-13 825208-448 1
19 nut, hex f pltd 3/8-16 825306-347 4
20 capscrew, hex gr5 1/2-13 x 1 1/4 829108-125 2
21 capscrew, hex gr5 1/2-13 x 1 3/4 829108-175 8
22 capscrew, hex gr5 1/2-13 x 2 1/4 829108-225 8
23 screw, hex ser washer 3/8-16 x 1 829706-100 4
24 washer, spr lock reg pltd 1/2 837808-125 18
25 plug, pipe 1/4” 3000# stl plt 866900-010 2
26 plug, pipe 1/2” 3000# stl plt 866900-020 2
27 bushing, red pltd 1/2 x 1/4 867102-010 1
(I) For maintenance on air inlet valve assembly no. 02250141-182, order repair kit no. 02250112-533, or
rebuild kit no. 02250112-534.
(II) For maintenance on air filter no. 048456, order primary replacement element no. 02250135-150, and
secondary replacement element no. 048463.
(III) When performing maintenance on the inlet valve assembly, if required, order gasket no. 242437-012
(quantity of 2).
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
Continued on page 49
Section 9
ILLUSTRATIONS AND PARTS LIST
47
