9.8 AIR PIPING SYTEM- WATER-COOLED
key part
number description number quantity
1 valve, ball 3/4” npt apollo 02250117-792 1
2 tube, mpv/aft clr ls20t wc 02250135-504 1
3 tube, aftclr/moist sep ls20t wc 02250135-508 1
4 support, moist sep ls20t 350psi 02250137-655 1
5 support, 3/4” cust conn mdrn ls20t 02250137-659 1
6 gasket, asa flange 300# 2” 240620-006 2
7 trap, auto 3/4”npt 400# max 250006-639 1
8 valve, mp/chk 2”350#wp (157#mp) (I) 250022-735 1
9 separator, water 2”w-a 31l 406746 1
10 elbow, pipe 45 deg 3/4” 300# 806430-030 1
11 connector, tube-m 2 x 2 810232-200 1
12 elbow, tube 90 deg m 3/4 x 3/4 810512-075 2
13 elbow, tube 90 deg m 2 x 2 810532-200 3
14 flange, thrd 2” 300# rf 820330-032 2
15 nut, hex pltd 5/16-18 825205-273 2
16 nut, hex pltd 1/2-13 825208-448 20
17 u-bolt,1/2” x 6” pipe 829008-600 2
18 capscrew, hex gr5 5/16-18 x 1 829105-100 2
19 capscrew, hex gr5 1/2-13 x 1 1/4 829108-125 4
20 capscrew, hex gr5 1/2-13 x 2 1/2 829108-250 16
21 washer, spr lock reg pltd 5/16 837805-078 2
22 washer, spr lock reg pltd 1/2 837808-125 24
23 tubing, stnls stl 3/4” 18ga. ft 841215-012 2
24 bulkhead, pipe 3/4” npt 841500-012 1
25 nipple, pipe-xs plt 3/4 x cl 866412-000 2
26 nipple, pipe-xs plt 3/4 x 2 866412-020 1
27 nipple, pipe-xs plt 3/4 x 5 1/2 866412-055 1
28 nipple, pipe-xs plt 2 x 4 866432-040 2
29 nipple, pipe-xs plt 2 x 6 866432-060 1
30 elbow, pipe 90 deg 300# plt 2” 867030-080 1
31 bushing, red pltd 1 x 3/4 867104-030 1
32 bushing, red pltd 2 x 1/4 867108-010 1
33 tee, pipe pltd 2 868430-080 1
34 union, pipe-brs seat 3/4 gal 300# 873530-030 1
35 connector, tube-m 1/4 x 1/4 ss 876804-025 1
(I) For maintenance on minimum pressure/check valve no. 250022-735, order repair kit no. 250022-736.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
Section 9
ILLUSTRATIONS AND PARTS LIST
57
